Continuous Rim Diamond Blade

• Place of Origin:

   China

• Type:

  Diamond Tools and Consumables

• Genre:

  Diamond Tools, Consumables and Stone Care Products

• sCode:

  STPR1277821

• Place of Origin:

  China
• It is being used a lot in the area of stone;These blades cut GENERAL TILE, CERAMIC TILE, PORCELAIN TILE, GRANITE, MARBLE etc.We produce them for GENERAL PURPOSE.Besides, we produce and design the blades so that the stone would not be chipped.

  Dimensions:
  Item No.  Diameter( Inch) /  (mm)   Hole Diameter (mm)  Segment Dimensions ThicknessxHeight(mm)
  LX/RW/105       4"/105       20     1.8 x 7.5
  LX/RW/110       4"/110       20     1.9 x 7.5
  LX/RW/114       4.5"/114       20     1.9 x 11.5
  LX/RW/115       4.5"/115       22.2     2 x 7.5
  LX/RW/125       5"/125       22.2     2.1 x 7.5

  LX/RW/150       6"/150      22.2/25.4      2.1 x 7.5
  LX/RW/180       7"/180      22.2/25.4      2.2 x 7.5
  LX/RW/200       8"/200      22.2/25.4          2.3 x 7.5
  LX/RW/230       9"/230      22.2/25.4       2.4 x 7.5
  LX/RW/250      10"/250      22.2/25.4       2.5 x 7.5
  LX/RW/300      12"/300      22.2/25.4          2.6 x 7.5
